1.8m³ Self-Loading Concrete Mixer Truck

Quantity:



Inquire Add to Basket

Type:
Concrete Mixing Truck
Shotcrete Type:
Wet
Machining Process:
Hydraulic
Structure:
Rotor Type
Productivity:
25m²/h
Feeding Height:
2050mm
Model NO.:
JSIEBC-18
Vibrating Amplitude:
Without
Condition:
New
Color:
White
Transport Package:
Nude Packing
Specification:
7300x2600x2750mm
Trademark:
JSIE
Origin:
China
HS Code:
8705400000
Production Capacity:
1000units/Year

Product Description

Data of complete
Overall dimension(LxWxH):7300x2600x2750mm
Wheelbase:2615mm
Curb weight:5666kg
Drive form: Torque converter
Top speed.: 30km/h
Maximum gradeability:30
Minimum turning radius;5270mm
Minimum ground clearance:280mm

Engine
Model: Quanchai 4C6
Rated power:78kw

Transmission case
Model: ZL-265 power shift gearbox
Gear: 4 forward 4 back

Conventional parameters
Equipment model: JSIEBC-18

:Maintain the amount of annotation
Fuel tank:63L
Total hydraulic system capacity : 63L
Oil: 16 liters

Parameters of hydraulic system
Reducer: HU80-43
Pump:FC 50/40
Motor:BM5-160

Water supply system parameters
Water tank capacity: 400L
Water supply mode: time relay
Stiring and unloading
The double cone roller has a double helical agitating screw and a convex bottom
Dum geometry capacity .2680L Drum rotation speed: 13 pm Concrete yield. 1.8CBM 1 can
The reaction frame mounted on the heavy duty' spherical saddle can be hydraulically rotated by 290 and automatically locked by a hydraulic brake Drum rotation is achieved via a gear pump and a plunger hydraulic motor in an open circuit with a manual electrical valve in the operator's room and at the rear of the mixer. The drum rises to a horizontal position through two double acting jacks. The unloading chute is tilted by manually adjustable handle and can be rotated by 90",but cannot be synchronized with the churning drum tilting operation, Removable chutes ensure unloading directly through the hopper, Two chute extensions are provided as standard.
