Euro 2
Automatic
3T
Diesel
Light
Dongfeng
New
Used for Road Motorcycle Obstacle Clearance
Nude
5995× 2200× 2280mm
JSIE
China
8705909990
5000units/Year
| TECHNICAL SPECIFICATION | |||||
| SER | ITEM | PARAMETER | UNIT | DATA | REMARK |
| 1 | WHOLE VEHICLE | VEHICLE MODEL | JSIEW5040TQZ1 | ||
| MANUFACTURE DATE | 2020 | ||||
| OVERALL DEMENSION | MM | 5995×2200×2280 | |||
| CURB WEIGHT | KG | 3600 | |||
| MAX GRADABILITY WHEN FULL LOADING | DEG | 30° | |||
| MAX SPEED | KM/H | 90 | |||
| FRONT/REAR HANGING | MM | 1032/1663 | |||
| CLOSE/DEPARTURE ANGLE | DEG | 19/12 | |||
| LEAF SPRING | PCS | 8/10+7 | |||
| DRIVE WHEEL | 4*2 | ||||
| 2 | CHASSIS | CHASSIS MODEL | EQ1060TJ20D3(DongFeng) | ||
| MANUFACTURER | DongFeng Motors Co.,Ltd. | ||||
| MANUFACTURE DATE | 2020 | ||||
| WHEELBASE | 3300 | ||||
| FRONT AXLE | 2T | ||||
| REAR AXLE | 3T | ||||
| TYRE SPECIFICATION | 7.00R-16 | ||||
| NO OF TYRES | PCS | 6+1 spare tyre | |||
| 3 | ENGINE | ENGINE MODEL | CY4102-C3F | ||
| MANUFACTER | DongFeng ChaoYang Diesel Motors Co.,Ltd. | ||||
| ENGINE HORSEPOWER | PS | 95 | |||
| DISPLACEMENT | ML | 3856 | |||
| EMISSION STANDARD | EURO II | ||||
| ENGINE DETAILS MORE | 4 CYLINDERS | ||||
| DIRECT INJECTIION | |||||
| WATERCOOLED TURBOCHARGED | |||||
| 4 | GEARBOX | NO OF GEARS | 5 forward gears and 1 reverse | ||
| RATIO | 5.125 | ||||
| 5 | UPPER | BRAND | JSIE | ||
| MANUFACTER | Xiamen Justsun Intelligent Equipment Co.,Ltd. | ||||
| LENGTH OF FLATBED | MM | 4200 | |||
| LENGTH OF TAIL PLATE | MM | 1000 | |||
| LENGHT OF WIRE ROPE | M | 21 | |||
| LIFTING WEIGHT | 3T | ||||
| DOUBLE LINKAGE OPERATION | Equipped | ||||
| HYDRUALIC SYSTEM | Equipped | ||||
| LED LIGHTS | Equipped | ||||
| BUNDLE | 4pcs | ||||
| AUTOMATIC SKATEBOARD | Equipped | ||||
| 6 | CAB | MODEL | DongFeng FRK | ||
| STEERING | Left hand drive | ||||
| TYPE | Flat proof | ||||
| SEATS | 3 | ||||
| COLOR | According to you | ||||
| A/C | According to you | ||||
| OTHERS | With FM RADIO,Spare tire stents and so on | ||||
