| specification | ||||
| Tank | volume | 50m³ | ||
| cross section shape | goose neck | |||
| material&thickness | tank body :5182 aluminum ,5mm end plate:5182 aluminum ,7mm | |||
| compartments | 7 compartments ,the same volume | |||
| compartments wall | number :6 pcs ;material :aluminum ,5mm | |||
| man hole | material :aluminum ;number :7pcs ;diameter :500mm | |||
| bottom valve | number :7 pcs | |||
| tool box | material :aluminum ;number :1 unit ;long :800mm | |||
| fuel discharge box | material :aluminum ;number :1 unit ;long :950mm | |||
| rear ladder | aluminum | |||
| top fence | aluminum | |||
| pipes | number :2 units ;install position :both sides ,aluminum discharge pipe :2 pcs ,joint DN80 | |||
| others | distinguish 2 units (8KG),electricstatic plastic tie 1 pcs ,distinguish hat 1 pcs | |||
| trailer chassis | axle | 3 axles Fuhua brand air suspension | ||
| tires | 385/65 R22.5 12 pcs | |||
| spare tire carrier | 1 pcs | |||
| leg | 28t 1 pair | |||
| ABS | 1 set | |||
| material | aluminum | |||
| others | overalldimension | 12550*2500*3850mm | ||
| net weight | 7100KG | |||
| defending | aluminum side fence :ground clearance ≤550mm rear fence :ground clearance ≤550mm; | |||
| lights & badge | standard | |||
